Advantage
- Increases Gas Velociy
- Low- Pressure Drop.
- Max separation efficiency upto 99%
- Improve gaseous phase quality.
- No loos of Liquid phase products.
- No Limitation in size& shape
- Easy to handle & install.
- No maintenance or service cost.
Material Composition:
Metallic Materials:
- Stainless Steel (SS 304, SS 316, SS 316L., SS 321, SS 430)
- Monel/ Nickel/Inconel/ Incoalloy/ Alloy20/ Copper.
- Hastelloy:/ SS Duplex 2205
Non-Metal/ Polymer Materials:
- Polypropylene (PP)
- FEP/ ETFE (Teflon)/ PVDF/ Hasteflon
- Fiberglass Co-Knitt
Pad Thickness:
Ranges from 100 mm to 300 mm depending on the process needs and required separation efficiency. Thicker pads offer better separation but may introduce higher pressure drops.
Applications:
- Gas moisture removal plants
- Food & Beverages
- Petro Chemical/
- Gas – Petroleum Refineries
- Thermal/Hydro & Nuclear Power Segments.
- Seawater Desalination plants
- Sulphuric acid plants
- Absorption Columns/ Stripper Columns/ 2 Phase 3 Phase Separator
- Oil separators/ Scrubber applications
Customization:
Available in different shapes and sizes to fit specific vessel dimensions and process conditions.
- Round shape.
- Rectangular shape.
- Ring shape.
- Customized shape.
